Best X870 Motherboards for Ryzen 9000 (2026): AM5 High-End Picks by Build Profile

X870E is AM5’s high-end platform tier, and most Ryzen 9000 builders do not need it. A quality B850 board feeds a Ryzen 7 9800X3D the same FPS. The X870E premium buys you USB4 as a platform standard, dual PCIe 5.0 x4 NVMe bandwidth, and a higher certified memory ceiling. If dual simultaneous NVMe, a USB4 dock, or 10GbE is part of the build, the upgrade earns its cost. These five boards cover every point on that X870/X870E ladder.

Our top pick: ASUS ROG Crosshair X870E Hero

The X870E Hero threads the needle between the entry tier and the enthusiast segment. It carries a capable 18+2+2 VRM with five M.2 slots, 10G LAN, dual USB4, and ASUS’s deepest BIOS, all on an ATX footprint that fits any standard mid-tower.

Quick picks

Specs at a glance

How we picked

The X870/X870E market splits by use case faster than by price. Boards at the same price point can target completely different buyers depending on VRM phase count, LAN tier, M.2 configuration, and form factor. We narrowed the field on five criteria.

VRM ceiling relative to CPU class. The Ryzen 9 9950X3D draws significantly more power in all-core workloads than a gaming-focused chip. Every board in this list handles a 9800X3D with headroom to spare. The Taichi’s 24+2+1 at 110A SPS is the clear leader for sustained AVX-heavy loads. The other four run the 9800X3D cooler than necessary.

LAN tier. For most gaming builds, 5G Ethernet is the ceiling that makes sense. The Hero and the Ace MAX are the only boards here that ship with 10GbE onboard, which matters for NAS-backed workstations and high-throughput local networks.

M.2 count and PCIe 5.0 coverage. X870E certifies at least two PCIe 5.0 x4 NVMe slots. The Hero and the Ace MAX hit five total slots with three and two Gen5 slots respectively. The Aorus Master has three Gen5 slots across four total. If dual full-bandwidth PCIe 5.0 NVMe is the requirement, every X870E board here satisfies it.

BIOS quality and OC tooling. ASUS’s BIOS stack is the benchmark in this segment. The Hero inherits the full Crosshair lineage with AI overclocking, Core Flex for P/E-core ratio tuning, and deep DDR5 sub-timing controls. ASRock’s Taichi BIOS is competitive for manual OC, especially memory. Gigabyte’s BIOS is solid and the EZ-Latch makes physical builds faster.

Form factor. Four of the five picks are ATX. The Taichi is E-ATX, which requires a case that clears the extra width. Most standard mid-towers handle E-ATX but measure before buying. We cross-referenced specs against manufacturer pages and independent reviews from TechPowerUp, Tom’s Hardware, and Tweaktown. No boards flagged by Hardware Unboxed as stock-only are included.

Best Overall: ASUS ROG Crosshair X870E Hero

ASUS ROG Crosshair X870E Hero AMD X870E AM5 ATX Motherboard, Advanced AI PC Ready, 18+2+2 Power Stages, DDR5, PCIe® 5.0, 5X M.2, Wi-Fi 7, USB4®, AI Overclocking, Core Flex, PCIe Slot Q-Release Slim

$558.00$599.99

Buy the ASUS ROG Crosshair X870E Hero on Amazon

Specs

What it does well

The X870E Hero lands the full Crosshair feature set on an ATX footprint without the E-ATX clearance requirement of the Taichi or the price ceiling of the X870E Extreme. Five M.2 slots with three running at PCIe 5.0 x4 bandwidth means a boot drive, a scratch drive, and a backup drive all run at peak throughput simultaneously. The 10G LAN is a genuine workstation feature at this price point and gives the Hero a clear argument over the Gigabyte Aorus Master for builders using NAS or high-throughput local storage.

The BIOS is where ASUS earns the premium. AI Overclocking reads CPU characteristics and auto-tunes frequencies without manual sub-timing work. Core Flex handles P-core and E-core ratio splitting for content creators running mixed workloads on a Ryzen 9 9950X3D or 9900X3D. The PCIe Slot Q-Release Slim makes GPU swaps tool-free, and the ROG SupremeFX ALC4082 audio codec is a step above the Realtek ALC4080 found on the competing boards in this list.

What you give up

The 18+2+2 VRM is capable but not the phase-count leader in this comparison. The Taichi’s 24+2+1 at 110A SPS has a higher ceiling for sustained all-core AVX loads on a 9950X3D. In gaming workloads and most productivity tasks, the Hero’s VRM never becomes the bottleneck. Only extreme OC workloads at elevated voltage expose the gap.

There are several X870E Hero variants that share similar product names. The BTF hidden-connector edition and the Dark Hero both command premiums above the standard Hero. Verify the ASIN before ordering. If 10G LAN is not part of the build plan, the Aorus Master covers the same X870E platform features at significantly less.

Who it’s for

The Ryzen 9 9950X3D or 9900X3D build where the buyer wants the best BIOS on the market, 10G networking, and a board that remains competitive through one more AM5 CPU generation. Also the right pick for content creators who rely on USB4 docks for external displays or high-speed storage arrays. If the build is a gaming-only Ryzen 7 9800X3D paired with a single NVMe, the Aorus Master saves real money for the same in-game outcome. See our 9800X3D motherboard guide for B850 alternatives in the same tier.

Best Value: MSI MAG X870 Tomahawk WiFi

MSI MAG X870 Tomahawk WiFi Gaming Motherboard (AMD Ryzen 9000/8000/7000 Series Processors, AM5, DDR5, PCIe 5.0, M.2 Gen5, SATA 6Gb/s, USB 40Gbps, HDMI/DP, Wi-Fi 7, Bluetooth 5.4, 5Gbps LAN, ATX)

$209.99$224.90

Buy the MSI MAG X870 Tomahawk WiFi on Amazon

Specs

What it does well

The Tomahawk WiFi is the entry point into the X870 platform bracket and carries most of what builders actually use at a price that competes directly with premium B850 boards. Two USB4 ports at 40Gbps are standard on every X870 board, and this one ships them at the same base price tier as a well-equipped B850. Two PCIe 5.0 x4 M.2 slots cover the dual-fast-drive use case that B850 can’t match at a single slot.

MSI’s Tomahawk line has a strong reputation for real-world stability. The 14+1+1 VRM at 80A per phase runs a Ryzen 7 9800X3D or a 9700X at reasonable temperatures with no thermal throttle during sustained gaming sessions. The USB rear I/O is dense: nine USB-A ports plus three USB-C ports gives a full desk setup room to breathe without a hub.

What you give up

X870 (non-E) is a lower certification tier than X870E. The Tomahawk ships with USB4 and dual PCIe 5.0 M.2 in practice, but without the X870E platform guarantee. The 14+1+1 VRM at 80A leaves less thermal headroom for a Ryzen 9 9950X3D under sustained AVX-heavy workloads. LAN tops out at 5Gbps. No path to 10GbE without an add-in card.

There is also a version split in the Tomahawk lineup. The X870 Tomahawk (non-E, this pick) is the value anchor. The X870E Tomahawk WiFi runs roughly fifty dollars more and adds X870E platform certification, an 80A SPS bump, and 5G over 2.5G LAN. For most builders, that step up is worth taking to land on X870E. This guide includes the non-E Tomahawk as the entry point, but the X870E Tomahawk is the stronger platform buy if budget allows.

Who it’s for

The builder who wants X870 platform features at the lowest entry price, pairing a Ryzen 7 9800X3D or Ryzen 5 9600X with a single GPU and one or two NVMe drives. Also the right board for a USB4 dock user who doesn’t need 10GbE and isn’t spending extra to push memory past DDR5-7000.

Best for Overclocking: ASRock X870E Taichi

ASRock AMD X870E Taichi Ryzen Socket AM5 X870 Dual Channel DDR5 DIMMs 256 GB 8200 EATX Motherboard M.2 LED WiFi 7

$329.99

Buy the ASRock X870E Taichi on Amazon

Specs

What it does well

The Taichi is the phase-count leader in this comparison. At 24+2+1 with 110A Smart Power Stage throughout the VCore rail, the board runs a Ryzen 9 9950X3D in sustained all-core AVX workloads with VRM temperatures that stay meaningfully cooler than the 16+2+2 and 18+2+2 alternatives. The E-ATX form factor adds thermal real estate for heatsink coverage that the ATX competition can’t match at the same VRM weight.

ASRock’s BIOS on the Taichi is built around manual tuning. DDR5 memory overclocking past 7200 MT/s has better platform support here than on most competing boards, and the Taichi routinely appears in high-frequency OC validation results from the competitive memory tuning community. Bifurcation support on both PCIe 5.0 x16 slots makes NVMe RAID or dual-GPU workstation configurations feasible.

What you give up

E-ATX means the case matters. Most standard mid-towers support E-ATX but the extra 30mm of board width can conflict with certain fan mount positions and GPU clearance configurations. Measure the case’s listed E-ATX support before building. The Taichi is a performance-first platform. The BIOS depth that enables the OC ceiling also means there are more settings to misconfigure. Builders who want self-tuning get more from the Hero; builders who want to manually push sub-timings get more from the Taichi.

5G LAN is the networking ceiling. For a NAS workstation where 10GbE would be used daily, the Hero or the Ace MAX are stronger picks.

Who it’s for

Builders pairing a Ryzen 9 9950X3D or competing on DDR5 OC frequency validation, where VRM headroom and BIOS granularity are the deciding factors. Also the right board for a content creation workstation that runs sustained all-core encoding workloads and needs the highest thermal margin in the VRM. If the case supports E-ATX and the buyer’s priority is raw overclocking ceiling, this is the pick. Pair it with a capable cooler from our AIO cooler guide to get the most out of the platform.

Best Mid-Premium: Gigabyte X870E Aorus Master

GIGABYTE X870E AORUS Master Motherboard - Supports AMD Ryzen 9000 CPUs, 16+2+2 Phases Digital VRM, up to 8200MHz DDR5 (OC), 4xPCIe 5.0 + 4xM.2, Wi-Fi 7, 5GbE LAN, USB 3.2 Gen 2x2

$599.95

Buy the Gigabyte X870E Aorus Master on Amazon

Specs

What it does well

The Aorus Master is the strongest value case in the X870E ATX bracket. Three PCIe 5.0 x4 M.2 slots across four total gives creators a boot drive, a scratch drive, and a high-speed archive slot all running at peak bandwidth. Gigabyte’s EZ-Latch makes tool-free M.2 swaps faster than any competing board in this guide, and Gigabyte backs this board with a 5-year warranty, notable in a segment where most boards ship with 3-year coverage.

Gigabyte’s BIOS has improved steadily across the AM5 generation. Auto overclocking profiles work reliably out of the box, and the fan curves are accessible without navigating deep sub-menus. The 16+2+2 VRM at 110A runs a Ryzen 7 9800X3D well within thermal limits and handles a 9950X3D in typical workloads.

What you give up

5GbE is the LAN ceiling. No 10G option without an add-in card. For a NAS-connected workstation, the Hero or the Ace MAX pull ahead here. The Realtek ALC1220 audio is a step behind the ROG SupremeFX ALC4082 in the Hero. The gap is audible on high-impedance headphones. Builders using a dedicated DAC or USB audio interface won’t notice.

At 16+2+2 phases, the VRM has less thermal margin than the Taichi’s 24+2+1 when a 9950X3D is running sustained all-core AVX. For a gaming build or a workstation that peaks at moderate CPU utilization, the gap is irrelevant. For a fully loaded 9950X3D render node, the Taichi is the right board.

Who it’s for

The value-conscious X870E buyer who wants three PCIe 5.0 M.2 slots, a strong warranty, and Gigabyte’s ecosystem without paying the ROG or MEG brand premium. Pairs well with a Ryzen 7 9800X3D or Ryzen 9 9900X3D in a build where 5GbE networking is sufficient and the BIOS will be left mostly at stock. Check our how to choose a CPU and motherboard guide if X870E versus B850 is still an open question.

Best Enthusiast: MSI MEG X870E Ace MAX

MSI MEG X870E ACE MAX Motherboard, ATX - Supports AMD Ryzen 9000/8000 / 7000 Processors, AM5-64MB BIOS ROM, 110A SPS VRM, DDR5 Memory (up to 8400+ MT/s OC), M.2 & PCIe 5.0, USB4, Wi-Fi 7, 10G LAN

$699.99

Buy the MSI MEG X870E Ace MAX on Amazon

Specs

What it does well

The Ace MAX is the only board in this guide that ships with both 10GbE and 5GbE onboard simultaneously, which means the NAS link and the workstation link run independently without a switch. The 18x 110A SPS VRM with the MAX revision’s 64MB BIOS ROM gives the board a longer firmware support runway than comparable X870E boards with smaller ROMs.

Five M.2 slots covers the heavy storage builder. Only two run at PCIe 5.0 x4, but three Gen4 x4 slots for archival or secondary drives add real expansion capacity. The MSI MEG BIOS at this tier offers competitive DDR5 OC tooling and is more approachable than ASRock’s for builders who want tuning depth without the Taichi’s full manual-OC learning curve.

What you give up

Only two of the five M.2 slots run at PCIe 5.0 x4, compared to three Gen5 slots on the Aorus Master or the Hero. For a build using three active PCIe 5.0 drives simultaneously, the Aorus Master or the Hero is the better fit.

At roughly the same price as the X870E Hero, the Ace MAX trades the Hero’s third Gen5 M.2 slot and ROG SupremeFX audio for dual LAN and a larger BIOS ROM. That’s a compelling trade for workstation builders and a neutral-to-negative trade for audio-focused gaming rigs. The MAX suffix matters: the original MEG X870E Ace and the Ace MAX have different BIOS ROMs. The MAX (B0G4P65W1J) is the current shipping revision.

Who it’s for

The prosumer builder pairing a Ryzen 9 9950X3D who needs dual Ethernet (10G for NAS, 5G for workstation LAN), MEG-tier BIOS depth, and an ATX footprint that avoids the Taichi’s E-ATX case requirement. Also the right pick for a builder who wants maximum BIOS ROM longevity on the AM5 platform.

Bottom line

If you want the best all-around X870E board on ATX, the ASUS ROG Crosshair X870E Hero is the pick: 10G LAN, the best BIOS in the segment, five M.2 slots, and a VRM that handles anything from a 9700X to a 9950X3D. If 10G networking is not part of the build and saving money matters, the Gigabyte X870E Aorus Master covers the same X870E platform fundamentals at a lower price with three Gen5 M.2 slots. For serious DDR5 OC or sustained all-core loads on a 9950X3D, the ASRock X870E Taichi’s 24+2+1 VRM is the ceiling no ATX board in this guide matches. For the value entry into X870 platform features, the MSI MAG X870 Tomahawk WiFi brings USB4 and dual PCIe 5.0 M.2 without the flagship premium. If dual 10G+5G LAN and five M.2 slots on an ATX board is the requirement, the MSI MEG X870E Ace MAX is the only board here that delivers both.

For most gaming-focused Ryzen 9000 builds with a single GPU and one fast NVMe drive, a quality B850 board is the better dollar-per-frame choice. X870E earns its cost when the platform features you pay for are features you actually use.
